Cat Forklift Battery Size Chart
					© Copyright Giant Battery Co. 1996, 2007. All rights reserved.
CAT FORKLIFT MODEL	V		CAPACITY		BATTERY DIMENSIONS			TOTAL
BATTERY	O	BATTERY	6 HOUR  RATE		X	Y	Z	BATTERY
COMPARTMENT	L	TYPE			in.	in.	in.	WEIGHT
SIZE (Inches)	T		Ah	kWh	(Length)	(Width)	(Height)	(Lbs.)
© Copyright Giant Battery Co. 1996, 2007
FOUR WHEEL SIT DOWN RIDER [3000-4000 LBS.]
EC15	36v	18-85-19	765	26.6	35.18	25.81	22.62	2200
35.8 x 27.8 x 23.3	36v	18-85-17	680	23.8	33.38	25.69	22.62	1963
	48v	24-85-15	595	27.6	35.31	25.62	22.62	2227
Connector: SB-350 Gray, Position B, 24" Lead Length								1650 LBS - MINIMUM BATTERY WEIGHT
THREE WHEEL STAND-UP RIDER
EC15KS	36v	18-125-15	875	30.6	38.31	17.88	30.50	2347
38.0 x 18.5 x 32.3								2300 LBS - MINIMUM BATTERY WEIGHT
39.0 x 13.6 x 32.3	36v	18-125-11	625	21.8	38.00	13.50	30.50	1805
								1600 LBS - MINIMUM BATTERY WEIGHT
39.0 x 16.25 x 32.3	36v	18-125-13	750	26.3	38.13	15.63	30.50	2056
Connector: SB-350 Gray, Position B, 13" Lead Length								2000 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [3000-4000 LBS.]
EC18	36v	18-85-19	765	26.6	35.18	25.81	22.62	2200
35.8 x 27.8 x 23.3
	48v	24-85-15	595	27.6	35.31	25.62	22.62	2227
Connector: SB-350 Gray, Position B, 24" Lead Length								1650 LBS - MINIMUM BATTERY WEIGHT
THREE WHEEL STAND-UP RIDER
EC18KS	36v	18-125-11	625	21.8	38.00	13.50	30.50	1805
39.0 x 13.6 x 32.3								1600 LBS - MINIMUM BATTERY WEIGHT
39.0 x 16.25 x 32.3	36v	18-125-13	750	26.3	38.13	15.63	30.50	2056
	36v	18-125-13	750	26.3	38.13	15.88	30.56	2058
								2000 LBS - MINIMUM BATTERY WEIGHT
39.0 x 18.5 x 32.3	36v	18-125-15	875	30.6	38.31	17.88	30.50	2347
Connector: SB-350 Gray, Position B, 13" Lead Length								2300 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [4000 LBS.]
EC20	36v	18-85-25	1020	35.6	38.44	29.25	22.62	2752
39.9 x 30.5 x 23.3
	48v	24-85-19	765	35.5	38.44	29.88	22.62	2803
Connector: SB-350 Gray, Position B, 24" Lead Length								2200 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER
EC20K	36v	18-85-25	1020	35.6	38.44	29.25	22.62	2752
39.9 x 30.5 x 23.3
	48v	24-85-19	765	35.5	38.44	29.88	22.62	2803
Connector: SB-350 Gray, Position B, 24" Lead Length								2200 LBS - MINIMUM BATTERY WEIGHT
THREE WHEEL STAND-UP RIDER
EC20KS
39.0 x 18.5 x 32.3	36v	Contact GB
39.0 x 21.25 x 32.3	36v	Contact GB
Connector: SB-350 Gray, Position B, 13" Lead Length								2600 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [5000 LBS.]
EC25
39.9 x 30.5 x 23.3	36v	18-85-25	1020	35.6	38.69	29.69	22.88	2982
Connector: SB-350 Gray, Position B, 24" Lead Length								2900 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [5000-6000 LBS.]
EC25E
39.9 x 34.4 x 23.3	36v	18-85-29	1190	41.6	38.44	33.81	22.63	3218
	48v	24-85-21	980	44.2	38.38	32.69	22.63	3223
Connector: SB-350 Gray, Position B, 24" Lead Length								3100 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER
EC25K	36v	18-85-25	1020	35.6	38.69	29.69	22.88	2982
39.9 x 30.5 x 23.3
	48v	24-85-19	855	39.8	38.44	29.78	22.63	2937
Connector: SB-350 Gray, Position B, 24" Lead Length								2900 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER
EC25KE	36v	18-85-29	1190	41.6	38.44	33.81	22.63	3218
39.9 x 34.4 x 23.3
	48v	24-85-21	850	44.2	38.38	32.69	22.63	3223
Connector: SB-350 Gray, Position B, 24" Lead Length								3100 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER
THREE WHEEL STAND-UP RIDER
EC25KS	36v	18-125-19	1125	39.2	38.31	22.38	30.50	2949
39.0 x 23.75 x 32.3
Connector: SB-350 Gray, Position B, 13" Lead Length								2600 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [5000-6000 LBS.]
EC30	36v	18-85-29	1190	41.6	38.44	33.81	22.63	3218
39.9 x 34.4 x 23.3
	48v	24-85-21	850	44.2	38.38	32.69	22.63	3223
Connector: SB-350 Gray, Position B, 24" Lead Length								3100 LBS - MINIMUM BATTERY WEIGHT
THREE WHEEL SIT DOWN RIDER [3000 LBS.]
EP15T	36v	18-85-17	680	23.8	38.44	20.06	22.63	1920
39.6 x 20.6 x 24.4
	48v	24-85-13	510	23.8	38.00	20.50	23.25	1920
Connector: SB-350 Gray, Position D, 30" Lead Length								1900 LBS - MINIMUM BATTERY WEIGHT
40.1" clearance at top
THREE WHEEL SIT DOWN RIDER
EP16KT	36v	18-85-17	680	23.8	38.44	20.06	22.63	1920
40.0 x 20.9 x 24.8
	48v	24-85-13	510	26.6	38.00	20.56	22.62	1973
Connector: SB-350 Gray, Position B, 20" Lead Length								1910 LBS - MINIMUM BATTERY WEIGHT
THREE WHEEL SIT DOWN RIDER
EP18KT	36v	18-85-21	850	29.7	38.44	24.62	22.62	2338
40.0 x 24.9 x 24.8
	48v	24-85-15	665	31.0	38.19	23.50	22.62	2274
Connector: SB-350 Gray, Position B, 20" Lead Length								2200 LBS - MINIMUM BATTERY WEIGHT
THREE WHEEL SIT DOWN RIDER [3500-4000 LBS.]
EP18T	36v	18-85-21	850	29.7	38.44	24.62	22.62	2338
39.6 x 24.9 x 24.4
	48v	24-85-15	665	31.0	38.19	23.50	22.62	2274
Connector: SB-350 Gray, Position D, 30" Lead Length								2200 LBS - MINIMUM BATTERY WEIGHT
40.1" clearance at top
THREE WHEEL SIT DOWN RIDER
EP20KT	36v	18-85-21	850	29.7	38.44	24.62	22.62	2338
40.0 x 24.9 x 24.8
	48v	24-85-15	665	31.0	38.19	23.50	22.62	2274
Connector: SB-350 Gray, Position B, 20" Lead Length								2200 LBS - MINIMUM BATTERY WEIGHT
THREE WHEEL SIT DOWN RIDER [3500-4000 LBS.]
EP20T	36v	18-85-21	850	29.7	38.44	24.62	22.62	2338
39.6 x 24.9 x 24.4
	48v	24-85-15	665	31.0	38.19	23.50	22.62	2274
Connector: SB-350 Gray, Position D, 30" Lead Length								2200 LBS - MINIMUM BATTERY WEIGHT
40.1" clearance at top
THREE WHEEL SIT DOWN RIDER [PNUEMATIC TIRE]
F25	36v	18-85-17	680	23.8	38.44	20.06	22.63	1920
39.6 x 20.8 x 24.6
	48v	24-85-13	570	26.6	38.00	20.56	22.62	1973
Connector: SB-350 Gray, Position D, 30" Lead Length								1900 LBS - MINIMUM BATTERY WEIGHT
THREE WHEEL SIT DOWN RIDER [PNUEMATIC TIRE]
F30	36v	18-85-17	680	23.8	38.44	20.06	22.63	1920
39.6 x 20.8 x 24.6
	48v	24-85-13	570	26.6	38.00	20.56	22.62	1973
Connector: SB-350 Gray, Position D, 30" Lead Length								1900 LBS - MINIMUM BATTERY WEIGHT
THREE WHEEL SIT DOWN RIDER [PNUEMATIC TIRE]
F35	36v	18-85-21	850	29.7	38.44	24.62	22.62	2338
39.6 x 25.0 x 24.6
	48v	24-85-15	665	31.0	38.19	23.50	22.62	2274
Connector: SB-350 Gray, Position D, 30" Lead Length								2200 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [PNUEMATIC TIRE]
F40D
41.3 x 45.5 x 18.9	48v	Contact GB
Connector: SB-350 Gray, Position D, 30" Lead Length								2425 LBS - MINIMUM BATTERY WEIGHT
41.3 x 45.5 x 20.9	36v	Contact GB
Connector: SB-350 Gray, Position B, 18" Lead Length								2425 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [PNUEMATIC TIRE]
F40DSA
41.3 x 45.5 x 18.9	48v	Contact GB
Connector: SB-350 Gray, Position D, 30" Lead Length								2425 LBS - MINIMUM BATTERY WEIGHT
41.3 x 45.5 x 20.9	36v	Contact GB
Connector: SB-350 Gray, Position B, 18" Lead Length								2425 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [PNUEMATIC TIRE]
F50D	36v	Contact GB
41.3 x 45.5 x 18.9
Connector: SB-350 Gray, Position B, 18" Lead Length								3250 LBS - MINIMUM BATTERY WEIGHT
41.3 x 45.5 x 20.9	36v	Contact GB
Connector: SB-350 Gray, Position B, 18" Lead Length								3250 LBS - MINIMUM BATTERY WEIGHT
41.3 x 45.5 x 24.1	48v	Contact GB
Connector: SB-350 Gray, Position D, 30" Lead Length								3250 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [PNUEMATIC TIRE]
F50DSA	36v	Contact GB
41.3 x 45.5 x 18.9
Connector: SB-350 Gray, Position B, 18" Lead Length								3250 LBS - MINIMUM BATTERY WEIGHT
41.3 x 45.5 x 20.9	36v	Contact GB
Connector: SB-350 Gray, Position B, 18" Lead Length								3250 LBS - MINIMUM BATTERY WEIGHT
41.3 x 45.5 x 24.1	48v	Contact GB
Connector: SB-350 Gray, Position D, 30" Lead Length								3250 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [PNUEMATIC TIRE]
F60D
49.2 x 45.5 x 18.9	48v	Contact GB
Connector: SB-350 Gray, Position D, 30" Lead Length								3350 LBS - MINIMUM BATTERY WEIGHT
49.2 x 45.5 x 20.9	36v	Contact GB
Connector: SB-350 Gray, Position B, 18" Lead Length								3350 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [PNUEMATIC TIRE]
F60DSA
49.2 x 45.5 x 18.9	48v	Contact GB
Connector: SB-350 Gray, Position D, 30" Lead Length								3350 LBS - MINIMUM BATTERY WEIGHT
49.2 x 45.5 x 20.9	36v	Contact GB
Connector: SB-350 Gray, Position B, 18" Lead Length								3350 LBS - MINIMUM BATTERY WEIGHT
THREE WHEEL SIT DOWN RIDER [PNUEMATIC TIRE]
FC40	36v	18-85-21	850	29.7	38.44	24.62	22.62	2338
39.6 x 25.0 x 24.6
	48v	24-85-15	665	31.0	38.19	23.50	22.62	2274
Connector: SB-350 Gray, Position D, 30" Lead Length								2200 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [7000-12000 LBS.]
M100D	36v	18-85-33	1360	47.5	42.50	40.00	23.13	4050
43.3 x 40.6 x 24.0
	48v	24-85-27	1105	51.4	41.89	38.44	22.63	4028
Connector: SB-350 Gray, Position B, 24" Lead Length								3750 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [7000-12000 LBS.]
M120D	36v	18-85-33	1360	47.5	42.50	40.00	23.13	4050
43.3 x 40.6 x 24.0
	48v	24-85-27	1105	51.4	41.89	38.44	22.63	4028
Connector: SB-350 Gray, Position B, 24" Lead Length								4000 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER
M40	36v	18-85-25	1020	35.6	38.44	29.25	22.62	2752
40.2 x 30.5 x 23.6
	48v	24-85-19	765	35.5	38.44	29.88	22.62	2803
Connector: SB-350 Gray, Position B, 24" Lead Length								2400 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER
M40DSA	36v	18-85-25	1020	35.6	38.44	29.25	22.62	2752
40.2 x 30.5 x 23.6
	48v	24-85-19	765	35.5	38.44	29.88	22.62	2803
Connector: SB-350 Gray, Position B, 24" Lead Length								2400 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER
M50
40.2 x 33.3 x 23.6	36v	18-85-27	1235	43.2	38.44	31.63	22.63	3102
	48v	24-85-21	850	39.6	38.38	32.69	22.62	3070
Connector: SB-350 Gray, Position B, 24" Lead Length								2950 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER
M50DSA
40.2 x 33.3 x 23.6	36v	18-85-27	1235	43.2	38.44	31.63	22.63	3102
	48v	24-85-21	850	39.6	38.38	32.69	22.62	3070
Connector: SB-350 Gray, Position B, 24" Lead Length								2950 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [7000-12000 LBS.]
M70D	36v	Contact GB
43.3 x 40.6 x 24.0	48v	24-85-27	1105	51.4	41.89	38.44	22.63	4028
Connector: SB-350 Gray, Position B, 24" Lead Length								3400 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER [7000-12000 LBS.]
M80D	36v	Contact GB
43.3 x 40.6 x 24.0
	48v	24-85-27	1105	51.4	41.89	38.44	22.63	4028
Connector: SB-350 Gray, Position B, 24" Lead Length								3600 LBS - MINIMUM BATTERY WEIGHT
FOUR WHEEL SIT DOWN RIDER
MC60DSA	36v	18-85-29	1190	41.6	38.44	33.81	22.63	3218
40.2 x 34.4 x 23.6	36v	18-85-27	1235	43.2	38.44	31.63	22.63	3102
	36v	18-85-29	1330	46.4	38.50	33.81	22.62	3354
	48v	24-85-21	950	44.2	38.38	32.69	22.63	3223
Connector: SB-350 Gray, Position B, 24" Lead Length								3060 LBS - MINIMUM BATTERY WEIGHT
LOW LIFT WALKIE/RIDER, CENTER RIDE, TOW TRACTOR [8000 LBS.]
NDC100	24v	12-100-13	600	13.9	30.69	12.94	26.13	1135
31.5 x 13.4 x Open	24v	12-125-11	625	14.5	30.69	12.94	31.00	1220
	24v	12-125-13	750	17.5	30.69	12.94	31.00	1372
Connector: SB-175 Gray, Position B, 18" Lead Length
